ACORN 130

STRAIGHT STAIRLIFT

If your stairs run in a straight line from top to bottom, with no bends, turns or curves, then you’ll need a straight stairlift. It gets its name from the straight stairlift rail that the carriage moves up and down. A straight stairlift is the simplest to install and also the most affordable type, because the standard straight rail only needs cutting to length to fit the stairs. The Acorn 130 Straight Stairlift is the latest generation of its original ‘Superglide’ model and has been continually developed, refined and improved over almost 30 years.

Request Survey For Price
acorn 130 straight

A GREAT SOLUTION, STRAIGHT UP!

If the staircase that causes you a problem is a straight one, then the Acorn 130 is a simple, effective and cost-effective solution. Its single straight rail is made from light-but-strong extruded aluminium and is fixed to the stairs, not the wall. That means there’s no need for messy and disruptive structural work, and the stairlift can be removed almost without trace if it’s no longer needed. The Acorn 130 stairlift carriage is among the most compact on the market, making it ideal for narrower staircases. Installation usually takes only around an hour.

Safety

Several safety features are incorporated in the Acorn 130, including sensors which detect any obstruction on the stairs and automatically stop the stairlift.

  • AUTO-STOP SENSORS
  • CAR-STYLE SEATBELT
  • LOCKABLKE SWIVEL SEAT

Features

An ergonomic seat and backrest designed for comfort and stability is just one of the many features of the Acorn 130 Straight Stairlift.

  • ERGONOMIC DESIGN
  • INTUITIVE CONTROLS
  • EASY TO DEACTIVATE

GET A FREE PRICE QUOTE

Get in touch with a specialist to find out which stairlift is best for you!

Thank you for contacting us!

A stairlift specialist will be in touch with you as soon as possible!

SPECIFICATIONS

The seat, armrests and footrest of the Acorn 130 carriage all fold neatly away when not in use, making it easier to pass on the stairs. The stairlift’s maximum carrying capacity is 300lbs (19.9st), but a heavy duty version increases the carrying capacity to 350lbs (25st).

  • FOLDAWAY CARRIAGE DESIGN
  • CHOICE OF SEAT HEIGHT
  • HEAVY DUTY VERSION AVAILABLE
stairlift outline
Dimensions inch
Overall height 38.5
Height of Seat 17.25
Overall depth (from wall) 22.5
Overall depth (when folded) 12.25
Width of footrest 12.25
Overall width 23.25
Depth of seat 16
Specifications
Motor output speed 120mm/s | 4.8inches per second - No greater than 0.15 meters per second
Method of drive Rack and pinion
Power supply 24V DC (battery)
Maximum capacity 280lbs/127kg
Track Extruded aluminium
Mains supply 50-60Hz, 100-240V AC
